Portable, Quick Response, Availability, Household Emergency
◆ 2000W power can be further increased via parallel operation system, up to 10000W
◆ 2160Wh capacity and 3-hour charge time that minimizes operational downtime
◆ Lightweight chasis, foldable carrying handle and 2-wheel design makes it easy to traverse from one location to another
◆ UPS function (Uninterruptible Power Supply)
Model :
CPS-2000Ingress / Impact Protection :
IP65 / IK09Working Temperature :
-20℃ ~ 45℃Nominal Energy :
2160WhMaximum Output Power :
2000WWeight :
40kgCPS-2000 lightweight power station is mainly designed for temporary backup, but with parallel connection system it can also handle prolonged and operation.
It's the perfect solution for road maintenance services where you need to travel between site to site without access to grid power, its capacity and expansion capability will allow you to finish all work swiftly and with ease.
When parallel connected with one another, they can also support intensive full-time operation at a fixed worksite. Its UPS function will activate within 10ms if main power supply is interrupted.
Rated capacity: 2160Wh
Power: 2000W
Overload power: 2500W
AC outlet: 100V grounded 2P x 2
DC outlet: USB-A x 1, USB-C x 1
AC charging time: 3 hours
Solar charging: up to 800W
Expansion 1: Use parallel cord to enable parallel operation with two units.
Expansion 2: Using the expansion connector, parallel operation with 3 to 5 units is possible.
Cycle life: Capacity ≥80% after 2000 charge-discharge cycles (under the condition of 25℃ ambient temperature)
Fire extinguishing device: Aerosol type (oxygen cutoff)
UPS (Uninterruptible Power Supply): Operation switching time ≤10ms (milliseconds)
Application scenarios
製品規格
| Model | CPS-2000 |
| Rated capacity | 2160 Wh |
| Rated power | 2000 W |
| Charging time | ≈3 hours (under the condition of 25℃ ambient temperature) |
| Weight | ≈40kg |
| Dimension | L565 x W468 x H440 mm |
| Battery type | Lithium iron phosphate ion(LFP) |
| IP rating | IP54 |
| IK rating | IK09 |
| Rated voltage | 100VAC ±4% |
| Rated current | 20A |
| Frequency | 50Hz/60Hz |
| Outlet type | 125V・grounded 2P × 3 port |
